Rako WSR-DLI

SKU WSR-DLI

The Rako WSR-DLI is a wired single-room DALI controller for Rako wired (CAT5 / Rakom) systems. It addresses up to 64 DALI ballasts across up to 15 channels within one room, with DT6 and DT8 support for RGBW and tunable white. For several rooms, see the WMR-DLI.

Manufacturer: Rako
£525.60 inc VAT

Key features

Wired
  • DALI lighting control on a Rako system
  • Wired Rako system
  • Run from the keypad; the Rako app needs an RK-HUB or WK-HUB
Product details Manual
Got a Rako project? Need commissioning, a design, or help choosing wired, wireless or hybrid? Tell us about the house.

Why Rako WSR-DLI

Wired single-room DALI controller for Rako wired (CAT5 / Rakom) systems

DALI

Puts DALI fittings under a Rako keypad, so the room still has scenes rather than a row of switches.

Wired

Sits on the wired Rako network, so one keypad can run several modules on that floor.

Keypad scenes

The plate on the wall is everyday control. With a Hub, the same scenes also run from the Rako app.

What the Rako WSR-DLI is

The Rako WSR-DLI is a DALI interface for one room of a Rako wired system. The WMR-DLI covers up to 16 rooms, and the RSR-DLI is the wireless single-room version.

Where it sits in a Rako system

It connects to the Rako wired (CAT5 / Rakom) network by RJ11, cabled back to a RAK-LINK or RAK-STAR, and is controlled from wired keypads such as the WK-EOS-6. It is configured in RASOFT Pro; a WK-HUB adds app and voice control. See all Rako wired modules.

Ratings and limits

  • Up to 64 DALI ballasts
  • Up to 15 channels in a single room
  • DT6 and DT8 ballasts: RGBW and colour-tunable control

Power and connection

It takes 12V DC for the DALI side and 15V DC from the Rako wired network, which connects by RJ11 socket or Krone connector. The DALI line connects to a 4-way screw terminal. Rako's WSR-DLI instruction manual covers installation.

Fitting

It measures 190 x 105 x 66mm, weighs 280g and operates from +2°C to +40°C.

Questions

How many DALI ballasts can the Rako WSR-DLI control?

Up to 64, in up to 15 channels within one room.

What is the difference between the WSR-DLI and the WMR-DLI?

The WSR-DLI serves a single room; the WMR-DLI serves up to 16 rooms.

Does the WSR-DLI support tunable white?

Yes, with DT8 ballasts.

Rako app

Scenes from the keypad, and from the phone

This product sits in a Rako system. The keypad on the wall runs the room. With an RK-HUB or WK-HUB, the same scenes also run from the free Rako app.

  • Room scenes from the keypad on the wall
  • App control once an RK-HUB or WK-HUB is on the network
  • Voice, timers and holiday mode from the Hub
Download on theApp Store Get it onGoogle Play

The Rako app is published by Rako, and needs an RK-HUB or WK-HUB with firmware 3.7.6 or later.
