Rako RLED45CC1
Rako RLED45CC1
Rako RLED45CC1 – side and end dimension drawing with wiring

Rako

Rako RLED45CC1

SKU RLED45CC1

The Rako RLED45CC1 is a wireless single-channel constant-current LED dimmer for constant-current fittings in a Rako wireless (Rakom RF) system. It is set to the fitting's current, from 350mA to 1000mA, and dims on commands from any Rako transmitter. Rako rates it at up to 45W and 45V forward voltage. It needs a separate 48V DC supply. Add an RK-HUB for app control.

Manufacturer: Rako
£201.60 inc VAT

Key features

Wireless
  • Constant current LED driver
  • Rated at 45 W
  • Wireless Rako system
  • Run from the keypad; the Rako app needs an RK-HUB or WK-HUB
Product details Manual
Got a Rako project? Need commissioning, a design, or help choosing wired, wireless or hybrid? Tell us about the house.

Why Rako RLED45CC1

Is set to the fitting's current, from 350mA to 1000mA, and dims on commands from any Rako transmitter

45 W LED

A constant current driver for LED tape or fittings, rated at 45 W.

Wireless

In-line on a wireless Rako system. The keypad in the room talks to this driver over Rakom RF.

Scenes

Colour temperature and levels are stored as Rako scenes, recalled from the plate or the app.

What the Rako RLED45CC1 is

The Rako RLED45CC1 is a single-output constant-current LED dimmer with a built-in Rako wireless receiver. It supports 350, 500, 600, 700 and 1000mA loads. For four-channel colour fittings, the RLED20+CC4 is the matching module; for constant-voltage tape, see the RLED75CV1.

Where it sits in a Rako system

It is controlled from any Rako wireless transmitter, such as an RK-EOS-6 keypad or the RK-HUB. Program it with RASOFT Pro through a RAMPI or Hub, following Rako's wireless module setup guide. See all Rako wireless modules.

Ratings and limits

  • Output current: 350, 500, 600, 700 or 1000mA
  • Maximum load: 45W
  • Forward voltage: 3V to 45V; up to 13 LEDs in series
  • Minimum load: 3W

Power and connection

It runs from a 48V DC supply, which is not included, and communicates by FM radio at 433.9MHz. Rako's RLED45CC1 instruction manual covers installation.

Fitting

An in-line module for vertical or horizontal mounting in a dry, ventilated, accessible position. It measures 172 x 46 x 40mm, weighs 177g and operates from +2°C to +40°C.

Questions

What output currents does the Rako RLED45CC1 support?

350, 500, 600, 700 and 1000mA.

How many LEDs can the RLED45CC1 drive?

Rako quotes up to 13 LEDs in series, within 45W and 45V.

Does the RLED45CC1 need a power supply?

Yes. It needs a separate 48V DC supply.

Does the Rako RLED45CC1 need a hub?

No. Any Rako wireless transmitter, such as a keypad, can control it. An RK-HUB adds app control, voice assistants and timed events.

Rako app

Scenes from the keypad, and from the phone

This product sits in a Rako system. The keypad on the wall runs the room. With an RK-HUB or WK-HUB, the same scenes also run from the free Rako app.

  • Room scenes from the keypad on the wall
  • App control once an RK-HUB or WK-HUB is on the network
  • Voice, timers and holiday mode from the Hub
Download on theApp Store Get it onGoogle Play

The Rako app is published by Rako, and needs an RK-HUB or WK-HUB with firmware 3.7.6 or later.
