Rako RLED20+CC4
Rako RLED20+CC4
Rako RLED20+CC4 – side and end dimension drawing with wiring

Rako

Rako RLED20+CC4

SKU RLED20+CC4

The Rako RLED20+CC4 is a wireless four-channel constant-current LED dimmer for RGBW and other multi-channel constant-current fittings in a Rako wireless (Rakom RF) system. Each output is controlled independently for full colour mixing. Rako rates it at 20W a channel at 350, 500 or 700mA, with a 45V maximum forward voltage. It needs a separate 48V DC supply. Add an RK-HUB for app control.

Manufacturer: Rako
£237.60 inc VAT

Key features

Wireless
  • Constant current LED driver
  • Four output channels
  • Ceiling mount
  • Wireless Rako system
  • Run from the keypad; the Rako app needs an RK-HUB or WK-HUB
Product details Manual
Got a Rako project? Need commissioning, a design, or help choosing wired, wireless or hybrid? Tell us about the house.

Why Rako RLED20+CC4

Each output is controlled independently for full colour mixing

LED driver

A constant current driver for LED tape or fittings. Four channels, so one module can run more than one run of tape.

Wireless

In-line on a wireless Rako system. The keypad in the room talks to this driver over Rakom RF.

Scenes

Colour temperature and levels are stored as Rako scenes, recalled from the plate or the app.

What the Rako RLED20+CC4 is

The Rako RLED20+CC4 is a four-output constant-current LED dimmer with a built-in Rako wireless receiver, for four-channel constant-current fittings. For a single constant-current fitting, the RLED45CC1 is the matching module; for constant-voltage colour tape, see the RLED30CV4+.

Where it sits in a Rako system

It is controlled from any Rako wireless transmitter, such as an RK-EOS-6 keypad or the RK-HUB, stores up to 16 scenes and supports a colour wheel. Program it with RASOFT Pro through a RAMPI or Hub. See all Rako wireless modules.

Ratings and limits

  • Four channels, 20W each
  • Output current: 350, 500 or 700mA
  • Maximum forward voltage: 45V
  • Minimum load: 3W per channel

Power and connection

It runs from a 48V DC supply, which Rako says is not included and must be bought separately. It has a 2-way terminal for the supply and an 8-way terminal for the load, and communicates by FM radio at 433.9MHz. Rako's RLED20+CC4 instruction manual covers installation.

Fitting

For a ceiling void, or central mounting on the supplied bracket. It measures 172 x 46 x 40mm, weighs 178g and operates from +2°C to +40°C.

Questions

What fittings does the Rako RLED20+CC4 control?

Four-channel constant-current LED fittings, such as RGBW, rated 350 to 700mA and up to 20W a channel.

Does the RLED20+CC4 need a power supply?

Yes. It needs a separate 48V DC supply.

What is the difference between the RLED20+CC4 and the RLED45CC1?

The RLED20+CC4 has four 20W channels for colour fittings; the RLED45CC1 has one 45W channel.

Does the Rako RLED20+CC4 need a hub?

No. Any Rako wireless transmitter, such as a keypad, can control it. An RK-HUB adds app control, voice assistants and timed events.
