Rako XCE-EOS-SB
Rako XCE-EOS-SB
Rako XCE-EOS-SB

Rako

Rako XCE-EOS-SB

SKU XCE-EOS-SB

The Rako XCE-EOS-SB is a surface-mount pattress for Rako EOS keypads: the RK-EOS wireless and WK-EOS wired modules, with RP-EOS or WP-EOS screwless cover plates. It suits UK and EU back boxes and measures 88 x 88 x 12.9mm. It fits the RK-EOS-6 and WK-EOS-6 keypads.

Manufacturer: Rako
£24.00 inc VAT

Key features

  • Cover plate or surround for a Rako keypad module
  • Choose the finish to match the room
  • Run from the keypad; the Rako app needs an RK-HUB or WK-HUB
Product details Manual
Got a Rako project? Need commissioning, a design, or help choosing wired, wireless or hybrid? Tell us about the house.

Why Rako XCE-EOS-SB

Suits UK and EU back boxes and measures 88 x 88 x 12.9mm

The plate

The visible finish on the wall. The keypad module sits behind it and sends the scenes.

Rako keypad

Sits on the CAT5 Rakom network with the modules for that floor.

App as well

With an RK-HUB or WK-HUB, the same scenes also run from the Rako app and from voice assistants.

What the Rako XCE-EOS-SB is

The Rako XCE-EOS-SB is the surface pattress for Rako's EOS keypads. For Classic keypads, use the RCE-CLASSIC-SB or WCE-CLASSIC-SB.

Where it sits in a Rako system

It houses an RK-EOS-6 or WK-EOS-6 keypad under the matching EOS cover plate kit, which is sold separately. With the RCE-WDGE adapter, a wireless RK-EOS keypad becomes freestanding. See the Rako EOS range.

Ratings and limits

  • Compatible keypads: RK-EOS (wireless) and WK-EOS (wired)
  • Cover plates: RP-EOS or WP-EOS ranges, sold separately
  • Wired WK-EOS use: minimum back box depth 36mm
  • Material: UL94 V-0 PC/ABS resin with steel and brass components

Fitting

Wall or back-box mounting with 4 x M3 x 5mm pan-head screws; suits UK and EU back boxes. It measures 88 x 88 x 12.9mm and weighs 64g. Rako publishes separate instruction manuals for RK-EOS and WK-EOS use.

Guide: Rako RK-EOS-6 vs WK-EOS-6: wireless or wired six-button keypad?

Questions

Which keypads fit the Rako XCE-EOS-SB?

RK-EOS wireless and WK-EOS wired keypads, such as the RK-EOS-6 and WK-EOS-6.

Does the XCE-EOS-SB include a cover plate?

No. RP-EOS or WP-EOS cover plates are sold separately.

Can the XCE-EOS-SB be freestanding?

Yes, with the RCE-WDGE adapter and an RK-EOS keypad.

Rako app

Scenes from the keypad, and from the phone

This product sits in a Rako system. The keypad on the wall runs the room. With an RK-HUB or WK-HUB, the same scenes also run from the free Rako app.

  • Room scenes from the keypad on the wall
  • App control once an RK-HUB or WK-HUB is on the network
  • Voice, timers and holiday mode from the Hub
Download on theApp Store Get it onGoogle Play

The Rako app is published by Rako, and needs an RK-HUB or WK-HUB with firmware 3.7.6 or later.
