Rako WCE-CLASSIC-SB
Rako WCE-CLASSIC-SB
Rako WCE-CLASSIC-SB

Rako

Rako WCE-CLASSIC-SB

SKU WCE-CLASSIC-SB

The Rako WCE-CLASSIC-SB is a surface-mount pattress for Rako Classic WCM wired keypads with WLH screwless cover plates. It lets a wired Classic keypad be surface mounted over a standard UK or EU back box at least 36mm deep. It measures 88 x 88 x 12.3mm. The RCE-CLASSIC-SB is the wireless version.

Manufacturer: Rako
£24.00 inc VAT

Key features

Wired
  • Cover plate or surround for a Rako keypad module
  • Choose the finish to match the room
  • Wired Rako system
  • Run from the keypad; the Rako app needs an RK-HUB or WK-HUB
Product details Manual
Got a Rako project? Need commissioning, a design, or help choosing wired, wireless or hybrid? Tell us about the house.

Why Rako WCE-CLASSIC-SB

Lets a wired Classic keypad be surface mounted over a standard UK or EU back box at least 36mm deep

The plate

The visible finish on the wall. The keypad module sits behind it and sends the scenes.

Wired

Sits on the CAT5 Rakom network with the modules for that floor.

App as well

With an RK-HUB or WK-HUB, the same scenes also run from the Rako app and from voice assistants.

What the Rako WCE-CLASSIC-SB is

The Rako WCE-CLASSIC-SB is a surface-mount pattress for wired Classic keypads. The RCE-CLASSIC-SB is the equivalent for wireless RCM and RNC keypads.

Where it sits in a Rako system

It houses a WCM keypad module under a WLH cover plate, which Rako sells separately; the keypad is cabled to the Rako wired network. See the Rako Classic range and Rako plate finishes.

Ratings and limits

  • Compatible keypads: WCM
  • Cover plates: WLH range, sold separately
  • Minimum back box depth: 36mm
  • Material: UL94 V-0 PC/ABS resin with steel and brass components

Fitting

Fixed with 4 x M3 x 5mm pan-head and 2 x M3.5 x 20mm countersunk screws; suits UK and EU back boxes. It measures 88 x 88 x 12.3mm and weighs 70g. Rako's WCE-CLASSIC-SB instruction manual covers fitting.

Questions

Which keypads fit the Rako WCE-CLASSIC-SB?

Rako Classic WCM wired keypads with WLH cover plates.

What back box does the WCE-CLASSIC-SB need?

A UK or EU back box at least 36mm deep.

Does the WCE-CLASSIC-SB include a cover plate?

Rako's datasheet lists WLH cover plates as sold separately.

Rako app

Scenes from the keypad, and from the phone

This product sits in a Rako system. The keypad on the wall runs the room. With an RK-HUB or WK-HUB, the same scenes also run from the free Rako app.

  • Room scenes from the keypad on the wall
  • App control once an RK-HUB or WK-HUB is on the network
  • Voice, timers and holiday mode from the Hub
Download on theApp Store Get it onGoogle Play

The Rako app is published by Rako, and needs an RK-HUB or WK-HUB with firmware 3.7.6 or later.
