Rako DIN-CONNECT
Rako DIN-CONNECT
Rako DIN-CONNECT – dimension drawing, front and end

Rako

Rako DIN-CONNECT

SKU DIN-CONNECT

The Rako DIN-CONNECT is a small RJ45 to punch-down connector that links a Rako DIN-LINK to the Rako wired (CAT5 / Rakom) network. Its 8-way Krone connector takes up to two CAT5 or CAT6 cables, for radial or star wiring. It connects to the DIN-LINK.

Manufacturer: Rako
£69.60 inc VAT

Key features

Wired
  • Network connection for the DIN system
  • Mounts on a standard DIN rail
  • Wired Rako system
  • Run from the keypad; the Rako app needs an RK-HUB or WK-HUB
Product details Manual
Got a Rako project? Need commissioning, a design, or help choosing wired, wireless or hybrid? Tell us about the house.

Why Rako DIN-CONNECT

Its 8-way Krone connector takes up to two CAT5 or CAT6 cables, for radial or star wiring

DIN-CONNECT

Joins DIN modules to the rest of the wired Rako system.

DIN-rail

Clips onto a standard DIN rail in the consumer unit or a Rako enclosure, next to the breakers it works with.

Keypad scenes

The plate on the wall recalls scenes. This module does the dimming or switching in the cupboard.

What the Rako DIN-CONNECT is

The Rako DIN-CONNECT is the network connection point for a Rako DIN installation. It turns the DIN-LINK's RJ45 port into punch-down terminals for the wired network cabling.

Where it sits in a Rako system

It connects by RJ45 to the DIN-LINK, and the wired network's CAT5 or CAT6 runs terminate on it, in radial or star arrangements. The DIN-LINK supports up to 30 wired devices this way. See the Rako DIN range.

Ratings and limits

  • RJ45 port to the DIN-LINK
  • 8-way Krone connector for up to two CAT5 or CAT6 cables

Power and connection

Passive connector; no power supply needed. Rako's DIN-CONNECT instruction manual covers installation.

Fitting

Screw fixed with a 3mm pan-head screw. It measures 67.6 x 32 x 22.5mm, weighs 30g and operates from +2°C to +40°C.

Questions

What does the Rako DIN-CONNECT do?

It links the DIN-LINK's RJ45 port to the Rako wired network's CAT5 or CAT6 cabling.

How many cables can the DIN-CONNECT take?

Up to two CAT5 or CAT6 cables on its 8-way Krone connector.

Does the DIN-CONNECT mount on the DIN rail?

Rako specifies a 3mm pan-head screw fixing rather than a DIN rail clip.

Rako app

Scenes from the keypad, and from the phone

This product sits in a Rako system. The keypad on the wall runs the room. With an RK-HUB or WK-HUB, the same scenes also run from the free Rako app.

  • Room scenes from the keypad on the wall
  • App control once an RK-HUB or WK-HUB is on the network
  • Voice, timers and holiday mode from the Hub
Download on theApp Store Get it onGoogle Play

The Rako app is published by Rako, and needs an RK-HUB or WK-HUB with firmware 3.7.6 or later.
